Fiber optic equipment optical transceiver 1.25g 1310/1550nm 20km bidi sfp module
$4.40
The SFP-BIDI transceivers are high performance, cost effective modules supporting dual data-rate of 1.25Gbps/1.0625Gbps and 20km transmission distance with SMF.The transceiver consists of three sections: a DFB laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit.
- Description
- Size Guide
- Reviews (0)
Description
Product Description
Fiber optic equipment optical transceiver 1.25g 1310/1550nm 20km bidi sfp module
The SFP-BIDI transceivers are high performance, cost effective modules supporting dual data-rate of 1.25Gbps/1.0625Gbps and 20km transmission distance with SMF.The transceiver consists of three sections: a DFB laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements.The transceivers are compatible with SFP Multi-Source Agreement . For further information, please refer to SFP.
Product Features :
Product Description
Specification
|
Data Rate
|
1.25G
|
Fiber Mode
|
Single Mode Fiber (SMF)
|
|
Types of Interface
|
LC
|
Types of Laser
|
DFB/FP
|
|
Operating Temperature
|
Standard 0~70°C
|
Operating Humidity
|
0%~90% RH (non condensing)
|
|
Transmission distance
|
3/20/30/40/60/80km
|
Modes of Communications
|
Simplex
|
|
Wavelength
|
1310nm TX/1550 nm RX
|
Types of Multiplexing
|
BIDI WDM
|
|
Receiver Sensitivity
|
<-23dBm
|
Extinction Ratio
|
>9dB
|
|
Form Factor
|
SFP BIDI
|
Power Consumption
|
<3W
|
|
Weight
|
0.024kg
|
Power Supply
|
+3.3V
|
|
Hot Pluggable Times
|
200
|
Average Output Power
|
-5 ~ -0dBm
|
